290HP Potable Water Truck 12000l Water Tank Capacity Single Row Cabin

Categories Water Tank Truck
Brand Name: Huilong
Model Number: Water Tank Truck
Certification: ISO9001
Place of Origin: Suizhou, China
MOQ: 1 unit
Price: Negotiable
Payment Terms: L/C, T/T
Supply Ability: 200 units per month
Delivery Time: 4~6 weeks
Packaging Details: in nude or by wax
Chassis Producer: Dongfeng Tianjin
Wheel Assembly: 4X2
Motor Power: 290hp
Gearbox System: 6 speed forward, 1 speed reverse
Seat Qty: 2
Water Tank: 12000L
  • Product Details
  • Company Profile

290HP Potable Water Truck 12000l Water Tank Capacity Single Row Cabin

290HP Potable Water Truck 12000l Water Tank Capacity Single Row Cabin


Description:


Main Application

Dongfeng water sprinkler truck has the valid capacity 12000L and is made by the Tianjin chassis. Tianjin sprinkler is also called tree sprinkling tanker and frequently used in landscaping, pavement cleaning and city environmental health. The sanitation truck consists of chassis, pumping system, and the tank. There are various functions covering sprinkling, water transport, emergent firefighting in different conditions.


Water Tank

5mm carbon steel is used for producing the water tank. The tank, cap and scleroseptum has the same thickness 6mm. The bottom of the tank is fixed on the subframe. The water level and volume can be measured by a water meter.


Advantages:


Tank Production

The automatic assembly line is applied in manufacturing the tank, including cutting, automatic welding, spinning forming etc.


Sprinkling System and Operation

One water pump is equipped for controlling the inlet and outlet of the water. Water spraying devices are also included. The water jet is installed to clean the street, remove dust in the air and cool. The direction and angle of the jet can be adjusted. The sprinkling width is between 14 m and 16m.


The gearbox is driven by the engine. Then, the PTO installed on the gearbox drives the spray pump. Finally, the liquid in the tank is pumped out through the pipeline.


Specifications:


Main Dimension7800x2500x2800mm
Tare Weight8200KGS
Truck Chassis
Chassis BrandDongfeng Tianjin
Driving Mode4X2
CabinSingle row cabin, 2 seats, with AC
Max Driving Speed90KM/H
Engine Horse Power290hp
Gearbox

Manual gear box,

6 speed forward,

1 speed reverse

Tyre11R22.5, 6pcs
Fabrication Part
Tank Body12000L water tank
Tank Parts

One manhole cover

one discharge valve

One set of water sprinkler front

One set of water sprinkler rear

One water pump

One water cannon rear

Gallery
