| Categories | Monocrystalline Solar Module |
|---|---|
| Brand Name: | URILIC |
| Model Number: | 80W, 85W |
| Certification: | UL,CE |
| Place of Origin: | China |
| MOQ: | 1pcs |
| Price: | Negotiation |
| Payment Terms: | T/T |
| Supply Ability: | 1000PCS/week |
| Delivery Time: | 5-15 days |
| Packaging Details: | Plywood box |
| Product name: | monocrystalline solar module |
| Power: | 80W, 85W |
| Size: | 765*666*30mm |
| Weight: | 7.0kg |
| Solar cell: | Mono 156*78 Cell |
| Frame color: | Silver or Black |
| Front cover: | 3.2mm High Transmission low Iron tempered glass |
| Solar panel: | Monocrystalline 80w 85W Solar Panel |
80W-85W-18V Solar Power Solar Panels Monocrystalline Solar Cells
Description:
The monocrystalline silicon solar panel is a module body in which a
single crystal silicon cell is formed in a different string and
array. The main advantages of single crystal plates are conversion
efficiency and smooth aesthetics. Monocrystalline Solar Panels have been the go-to the choice for
many years. They are among the oldest, most efficient and most
dependable ways to produce electricity from the sun. Each module is
made from a single silicon crystal and it is recognized by their
colour, which is typically black or iridescent blue.
Features:
Product Details:
| Model | U80M-12 | U85M-12 |
| Peak Power (W) | 80±3% | 85±3% |
| Open circuit voltage (V) | 21.6 | 21.6 |
| Peak Voltage (V) | 18.0 | 18.0 |
| peak current (A) | 4.45 | 4.72 |
| Short-circuit current (A) | 4.84 | 5.05 |
| Cell efficiency | 19.0% | 20.0% |
| Maximum overcurrent (A) | 10A | |
| Maximum system voltage (V) | 1000V DC | |
| Rated operating temperature | 48±2°C | |
| Working temperature range | -40°C- +85°C | |
| Current temperature coefficient | 0.1%/°C | |
| Voltage temperature coefficient | -0.37%/°C | |
| Power Temperature Coefficient | 0.45%/°C | |
| Solar Cell | 156*78*0.19mm | |
| Number of cells | 36 pcs | |
| Size | 765*666*30mm | |
| Weight | 7.0 kgs | |
| Surface Packaging | Low iron tempered glass/3.2mm | |
| Sealant | Ethylene Vinyl Acetate (EVA) | |
| Border | Anodized Aluminum/Silver | |
| Junction Box | Crimping + Welding Treatment | |
| Pre-wind pressure | 2400Pa | |
| Back wind pressure | 2400Pa | |
| Maximum hail impact | 25mm/ 23m/s | |
80W-85W-18V small solar panel assembly size chart
Our advantage:
| ||
Solar Cell High Efficiency PV Cells | Frame Frame thinkness>18mm Oxidation Film>15Pm TUV&UL standard sillica gel Ability to resist 5400Pa mechanical pressure Good anti-corruption performance in seaside environment | Solar junction box PPO material, IP67. Heat dissipation Long service life |
| |||
