| Categories | Gas LPG Tank |
|---|---|
| Brand Name: | CLW |
| Model Number: | ASME,CCC,SGS,BV |
| Certification: | CLW9522 |
| Place of Origin: | Suizhou, China |
| MOQ: | 1 Unit |
| Price: | negotiable |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 500 Units/Month |
| Delivery Time: | 20~30 days after receiving deposit |
| Packaging Details: | Naked Package,Bulk Ship,Roll-Roll |
| Size Option: | 10mt,15mt,20mt,30mt,40mt,50mt,60mt, |
| Material: | Carbon Steel Q345R |
| Filling Medium: | Propane,butane |
| Tank Diameter: | DN2700mm |
| Design Pressure:: | 1.71Mpa |
| Hydraulic Test Pressure: | 2.21MPa 22.1bar |
| Level Gauge: | Rotogage Or Megnatic Type |
| Tank Valves: | Cut-off Valve, Needle Valve, Safety Valve, Return Valve etc.. |
| LOGO: | As per request |
| Warranty: | one year |
| Diagram: | yes |
| Shell Thickness: | 14 mm |
| End Thickness: | 16 mm |
| Corrosion Allowance: | 1 mm |
| Usage: | LPG Gas Storage, Station Tank |
| Life Time: | 20 years |
60cbm LPG Storage Tank Liquid Propane Ammonia Butane Gas Bullet Tank for Gas Station
Product Description
1. Storage medium of lpg gas plant tank : LPG, Liquid
ammoina,Dimethyl ether,Iso-butane,Pentane and etc.
2. Available tank capacity of lpg gas plant tank :
5m³~200m³,2ton~100tons
3. Manufacturing standards of lpg gas plant tank : GB-150, ASME
VIII Division I U STAMP, CCC, ISO9001 : 2008
4. Optional for lpg gas plant equipments as follows, lpg pump and
motor,lpg compressor,volume flow meter,filling scales and lpg
dispenser,ball valves,check valves,non-return valves,glass
valve,strainer,by-pass valve and so on.
Specification of 30mt filling station gas tank
| Parameter of 60000liters 30tons filling station gas tank | ||||||
| ITEM | PARAMETER | ITEM | PARAMETER | |||
| Volume | 60cbm | Thickness of Shell | 14mm | |||
| Tank Material | Q345R | Thickness of End plate | 16mm | |||
| Overall Size | 10962*2728*3318mm | Tank Net Weight | 12750kg | |||
| Tank Diameter | 2700mm | Loading Capacity | 23940kg | |||
| Design Pressure | 1.77Mpa | Gas Density | 420kg/M3 | |||
| Hydraulic Test Pressure | 2.22Mpa | Corrosion Allowance | 1mm | |||
| Design Temperature | -20ºC~60ºC | Heat Treatment | Bulk | |||
| Vapor Outlet | DN50 | Gas Outlet | DN50 | |||
| Life time | 15 years | |||||
| Accessories | ||||||
| Model | Item | Qty | Junction surface | |||
| J41N-2.5-50 | Stop Valve DN50 | 6 | RF | |||
| J41N-2.5-25 | Stop Valve DN25 | 2 | RF | |||
| J41N-2.5-100 | Stop Valve DN100 | 1 | RF | |||
| J24W-320-DN6 | J24W Needle Valve M20*1.5 | 1 | ||||
| HG21584-95 | Magnetic plate level Gauge UZFAL-2.5RF-3040-0.5 | 1 | RF | |||
| A42F-25-100 | Safety Valve DN100 | 1 | RF | |||
| Y-100T | Pressure Gauge M20*1.5 1.5degree 0~4Mpa | 1 | ||||
| WTQ-280 | Thermometer M33*2 2.5 degree | 1 | -40ºC~60ºC | |||



|
