Oil Tanker Truck Gasoline Delivery 4X2 6X4 8X4 17cbm 17000 Liters Fuel Transport Euro 2 3 4 5 Gas Fuel Tanker Truck

Categories Fuel Oil Tanker Truck
Brand Name: Huate
Place of Origin: Hubei, China
Price: $15,800/sets 1-49 sets
Condition: New
Storage: Oil
Drive Wheel: 4X2
Horsepower: 150 - 250hp
Transmission Type: Manual
Fuel Type: Diesel
Tank Volume: 15001 - 30000L
Dimensions (L x W x H) (mm): 6400 X 2200 X 2750 mm
Gross Vehicle Weight: 15-20T
After-sales Service Provided: Onsite Installation, Video technical support, Online support, Free spare parts
Capacity (Load): 11 - 20T
Engine Capacity: 4 - 6L
Forward Shift Number: 8
Maximum Torque(Nm): ≤500Nm
Fuel Tank Capacity: 100-200L
Product Name: Fuel Tank Truck
Medium: Gasoline, Kerosene, Diesel and Jet Fuel
Drive Method: Left Hand Drive
Tank Material: Carbon Steel
Engine: Yunnei
Color: Customer's Require
Warranty: 1 Year
Tank capacity: 19CBM
Horse power: 98HP~570HP
MOQ: 1
Packaging Details: Wooden box
Delivery Time: 7-30 days
Payment Terms: T/T
Supply Ability: Meet large-scale orders
  • Product Details
  • Company Profile

Oil Tanker Truck Gasoline Delivery 4X2 6X4 8X4 17cbm 17000 Liters Fuel Transport Euro 2 3 4 5 Gas Fuel Tanker Truck

Products Description
Customized Oil Transport Tank Truck Fuel Tanker Truck is also known as tanker truck, highway tanker, etc. It is mainly used for transportation and storage of oil products such as petroleum derivatives, gasoline, diesel, crude oil, lubricating oil and coal tar. Tanker trailers are widely used in oil
depots, gas stations, oil fields, chemical plants, food plants, asphalt plants, etc.
The tank body of fuel tanker trailer can be made of different materials such as aluminum, carbon steel, and stainless steel.
The tank is built with multi-channel reinforced anti wave baffle plate, and the lower end of the baffle plate is designed with
through holes to reduce the impact of fuel in the tank and improve the strength of the tank.
The combined tank opening is located at the top of the tank body. A self-locking small cover is arranged on the large cover, and a breathing valve is installed on top of the large cover to ensure the consistency of atmospheric pressure inside and outside the tank. There is also the electrostatic grounding wire. Installed fuel pump system allows the fuel tanker trailer to self-prime and self-drain. Two separate pumping pipes are included along with a suction lift, two fire extinguishers, and too
Product Name
Refuel Tank Truck
Driving Type
4x2
Driving Method
Left Hand Drive
Emission Standard
Euro 3 4 5 6 ,As Customer Required
GVW
11900kg
Total Net Weight
4905kg
Total Net Weight
6800kg
Tank Capacity( CBM )
19CBM
Medium
Fuel Such As: Gasoline, Kerosene, Diesel and Jet Fuel
Wheelbase (mm)
3390,3850(mm)
Driver’s Cabin
Flat roof cab with one narrow sleeper
Engine Model
YunneiD25TCIF1
Horsepower (hp)
199
Gearbox
FAST 12 gears
Approach/departure angle
21°/12°
Axle Loading
4.0T/7.7T
Tire
245/70R19.5 14PR,8.25R20 16PR,8.25R20 14PR,245/70R19.5 16PR
Truck frame
Double truck frame
Fuel tank(L)
19000
Walkway
On the top
Pedal
Anti-Skid Pedal
Color and Logo
As Customer Need
Selective Configuration
Ultifunctional Rear Lifting Part,Rear Handrail and Footplate,Other shapes of body etc.
*The right-hand drive truck model is optional.
The above parameters are only a reference. Please contact with us for specific configurations.
